Main Technical Parameters
Image Sensor | 2.0M, 1/3inches |
Effective Pixel | 1600*1200 |
Frame Rate | 15fps |
Definition | Max Over 800 Line (Horizontal) |
Housing | Standard Iron Housing or Custom |
Lens | CS for Test, Custom Provide |
White Balance | Auto |
Brightness Control | Auto |
Color | Color/Grayscale |
Negative Film | Support |
Mirror Image | Support Left/Right/Up/Down |
Freeze | Support |
OSD | English/Chinese |
Image Digital Zoom | Support 10times Digital Zoom |
Image Contrast | Support Static and Dynamic Pictures, 1/2 Screen Image Contrast |
Edge Enhancement | Support |
Contrast | Support |
Color Scale | Support |
Cross Cursor | Support Multi-color |
Transverse and Vertical Line | Support Multi-color, 2pcs of Transverse/Vertical Lines, Moveable |
Digital SNR | Support |
VGA (RGB) | 720P/1024*768/1280*1024/1366*768@60HZ |
USB Output | USB2.0 (1600*1200、800*600) Drive-free |
AV Interface | Cvbs Output NTSC and PAL Format |
